Produktkategori: SAE 37 deg flare fittings adaptere
Materiale: kulstofstål, rustfrit stål eller kobberlegering.
2GJ9-OG 90 ° BSPP MALE O-RING / JIC FEMALE 74 ° CONE Dimensionskort som følger:
PAR T NEJ . | THREA D | O-RIN G | DIMENSION S | ||||||
E | F | E | EN | B | S 1 | S 2 | S 3 | ||
2GJ9-04O G | G1 / 4 "X1 9 | 7/16 "X2 0 | 10.77X2.6 2 | 31. 3 | 9 | 1 4 | 1 5 | 1 9 | |
2GJ9-04-05O G | G1 / 4 "X1 9 | 1/2 "X2 0 | 10.77X2.6 2 | 31. 3 | 9 | 1 4 | 1 7 | 1 9 | |
2GJ9-04-06O G | G1 / 4 "X1 9 | 9/16 "X1 8 | 10.77X2.6 2 | 31. 3 | 10. 5 | 1 4 | 1 9 | 1 9 | |
2GJ9-04-08O G | G1 / 4 "X1 9 | 3/4 "X1 6 | 10.77X2.6 2 | 32. 5 | 10. 5 | 1 6 | 2 4 | 1 9 | |
2GJ9-06O G | G3 / 8 "X1 9 | 9/16 "X1 8 | 13.94X2.6 2 | 35. 8 | 10. 5 | 1 6 | 1 9 | 2 2 | |
2GJ9-06-08O G | G3 / 8 "X1 9 | 3/4 "X1 6 | 13.94X2.6 2 | 35. 8 | 10. 5 | 1 6 | 2 4 | 2 2 | |
2GJ9-08O G | G1 / 2 "X1 4 | 3/4 "X1 6 | 17.12X2.6 2 | 43. 2 | 10. 5 | 2 2 | 2 4 | 2 7 | |
2GJ9-08-06O G | G1 / 2 "X1 4 | 9/16 "X1 8 | 17.12X2.6 2 | 43. 2 | 10. 5 | 2 2 | 1 9 | 2 7 | |
2GJ9-08-10O G | G1 / 2 "X1 4 | 7/8 "X1 4 | 17.12X2.6 2 | 43. 2 | 1 2 | 2 2 | 2 7 | 2 7 | |
2GJ9-12O G | G3 / 4 "X1 4 | 1,1 / 16 "X1 2 | 23.47X2.6 2 | 49. 3 | 1 5 | 2 7 | 3 2 | 3 2 | |
2GJ9-12-08O G | G3 / 4 "X1 4 | 3/4 "X1 6 | 23.47X2.6 2 | 49. 3 | 10. 5 | 2 7 | 2 4 | 3 2 | |
2GJ9-12-10O G | G3 / 4 "X1 4 | 7/8 "X1 4 | 23.47X2.6 2 | 49. 3 | 1 2 | 2 7 | 2 7 | 3 2 | |
2GJ9-12-16O G | G3 / 4 "X1 4 | 1,5 / 16 "X1 2 | 23.47X2.6 2 | 5 2 | 1 6 | 3 0 | 4 1 | 3 2 | |
2GJ9-16O G | G1 "X1 1 | 1,5 / 16 "X1 2 | 29,74X3,5 3 | 5 3 | 1 6 | 3 3 | 4 1 | 4 1 | |
2GJ9-20O G | G1.1 / 4 "X1 1 | 1,5 / 8 "X1 2 | 37,69X3,5 3 | 5 8 | 1 7 | 4 1 | 5 0 | 5 0 | |
2GJ9-24O G | G1.1 / 2 "X1 1 | 1,7 / 8 "X1 2 | 44.04X3.5 3 | 6 3 | 2 0 | 4 8 | 5 5 | 5 5 | |
